BUNDY TUBE

Tin coated steel Brake line tube. Complies with SAE J527 standards. Comes as a 7.5 metre length.

Manufacturer: FAIRVIEW

TUBE O.D.	WALL THICKNESS	WORKING PRESSURE
3/16"	0.028"	5000 p.s.i
1/4"	0.028"	5000 p.s.i
5/16"	0.028"	5000 p.s.i
3/8"	0.028"	5000 p.s.i

NOTE: THE WORKING PRESSURES LISTED FOR THIS TUBE IS RATED AT 21°C. ANY AMBIENT OR INTERNAL INCREASE IN TEMPERATURE WILL LOWER THE ABOVE LISTED WORKING PRESSURES.

Overview

TUBE O.D.	WALL THICKNESS	WORKING PRESSURE
3/16"	0.028"	5000 p.s.i
1/4"	0.028"	5000 p.s.i
5/16"	0.028"	5000 p.s.i
3/8"	0.028"	5000 p.s.i

NOTE: THE WORKING PRESSURES LISTED FOR THIS TUBE IS RATED AT 21°C. ANY AMBIENT OR INTERNAL INCREASE IN TEMPERATURE WILL LOWER THE ABOVE LISTED WORKING PRESSURES.

Price	U.O.M	Item No	Description	Tube Od
$56.38	EACH	THBT316	3/16 X 7.5MTR OD BUNDY STEEL TUBE	3/16"
$63.17	EACH	THBT14	1/4 X 7.5MTR OD BUNDY STEEL TUBE	1/4"
$76.88	EACH	THBT516	5/16 X 7.5MTR OD BUNDY STEEL TUBE	5/16"
$88.39	EACH	THBT38	3/8 X 7.5MTR OD BUNDY STEEL TUBE	3/8"
